Product Description:

The Ace A-750BR 750W ATX Power Supply is a cost-effective replacement or system-building PSU for home computers, office workstations and general-purpose desktop PCs.

It features a 120mm cooling fan for quiet operation and effective ventilation, together with Power Factor Control and built-in electrical protection. Its standard ATX dimensions make it suitable for many conventional desktop cases.

A useful selection of motherboard, CPU, PCIe, SATA and Molex connectors provides compatibility with a wide range of components. The 6+2-pin PCIe connector can support compatible graphics cards requiring either a six-pin or eight-pin power connection.

Key Features:

  • 750W Rated Output – Designed to power compatible desktop PC components.
  • Standard ATX Form Factor – Suitable for many conventional desktop and tower cases.
  • 120mm Cooling Fan – Provides effective airflow while maintaining quiet operation.
  • Power Factor Control – Helps provide stable power delivery.
  • 6+2-pin PCIe Power Connector – Compatible with supported graphics cards requiring a six-pin or eight-pin connection.
  • Multiple Drive Connections – Includes four SATA and three Molex power connectors.
  • Built-in Protection – Includes over-voltage, under-voltage and over-power protection.
  • Versatile Replacement PSU – Suitable for upgrading or repairing many existing desktop systems.

Example Uses:

  • Building an affordable home or office desktop PC.
  • Replacing a failed standard ATX power supply.
  • Powering compatible older or general-purpose computer systems.
  • Supporting a modest graphics card requiring one PCIe power connector.
  • Providing power for systems containing multiple SATA or legacy Molex devices.

Connectors:

  • Motherboard: 1 × 20+4-pin ATX
  • CPU: 1 × 4+4-pin EPS/ATX12V
  • PCIe: 1 × 6+2-pin PCIe
  • SATA: 4 × SATA
  • Molex: 3 × 4-pin Molex

Technical Specifications:

  • Manufacturer: Ace
  • Model: A-750BR
  • Power Rating: 750W
  • Form Factor: ATX
  • Input Voltage: 230V AC
  • Input Frequency: 50–60Hz
  • Cooling: 120mm fan
  • Efficiency: 75% stated
  • Protection: OVP, UVP and OPP
  • Dimensions: Approximately 150 × 140 × 85mm
  • Colour: Black
  • EAN: 5055492400086

Important Compatibility Information:

Please check that your computer requires a standard ATX power supply and uses the connections listed above before ordering.

This PSU provides one 6+2-pin PCIe connector. It is therefore unsuitable for graphics cards requiring two or more dedicated PCIe power connections. A mains power cable is not included.

Brand New - ACE 750W ATX PC Power Supply

  • Product Code: Ace-750
  • Availability: 25
  • £27.50


Tags: ACE, 750W, ATX, PC, Power, Supply
